DESCRIPTION

Kanga Subsoil Cultivator Tines are sold individually for fitting to compatible Kanga subsoil cultivator toolbars. Select the tine type and quantity to build a cultivation setup around your tractor horsepower, soil conditions, desired working depth and required spacing.

The cast shear-bolt tine options are suited to ripping and cultivation where minimal surface disturbance is preferred. Their pointed leading edge creates narrow rip lines that help guide moisture, organic matter and nutrients into the subsoil while retaining surface cover.

The Stump Jump Chisel Plough Tine is spring protected for primary cultivation in hard, rocky or uneven ground. Its spring-loaded design lets the tine deflect around an obstruction, helping reduce the risk of damage and maintain practical operation in challenging conditions.

Choose the right tine

  • 24in Cast Shear Bolt Tine: 610mm working depth, 10-15hp per tine and 5000kg shear-pin breakout protection.
  • 30in Cast Shear Bolt Tine: 760mm working depth, 12-15hp per tine and 5000kg shear-pin breakout protection.
  • Stump Jump Chisel Plough Tine: 520mm working depth, 8-10hp per tine and spring protection rated at 250lb/ft (370kg/m).

Important selection notes

Working depth is measured from the bottom of the toolbar and includes the point. Confirm tine quantity, toolbar width, tractor horsepower and ground conditions before ordering. Cast shear-bolt tine options use replaceable shins and points to support ongoing maintenance.

FEATURES

  • Individual tines for compatible Kanga subsoil cultivator toolbars
  • Cast shear-bolt and spring-protected tine options
  • 610mm, 760mm and 520mm working-depth options
  • Cast shear-bolt tine options with 5000kg breakout protection
  • Stump Jump Chisel Plough Tine with 250lb/ft spring protection
  • Select tine type and quantity to suit the toolbar, tractor and soil conditions
  • Cast shear-bolt tine options use replaceable shins and points

Product Details

SPECIFICATIONS

SKU KSST
Brand Farm Implements
Shipping Weight 29.0000kg
Shipping Height 0.400m
Shipping Length 0.800m
Unit Of Measure ea
